High Precision BMS Battery Cell Sampling Discharge Transition Wiring Harness

This battery sampling and discharge adapter harness, designed specifically for new energy vehicles, accurately captures core operational data such as cell voltage, temperature, and current. It provides stable and reliable signal transmission for battery balancing management and safety protection against overcharging and over-discharging, ensuring the safe and efficient operation of the power battery. Additionally, it integrates battery discharge circuits with power supply adapter functions, enabling seamless and stable connectivity between the battery pack and the vehicle’s electronic control and charging systems, thereby optimizing the vehicle’s current distribution logic.
Key Advantages
1. High-precision signal acquisition and transmission. Stably transmits comprehensive cell status data, precisely coordinating with the BMS (Battery Management System) to achieve comprehensive safety protection against cell imbalance, overcharging, overheating, and over-discharging.
2. Compatibility with internal layouts and interface specifications of battery packs across multiple vehicle models. Compatible with various BMS controller models; wiring definitions can be flexibly adjusted to ensure error-free integration.
3. Highly reliable electrical connection performance. Resistant to high temperatures and bending, with strong resistance to electromagnetic interference; low-voltage signals remain undiminished, and high-voltage circuits do not overheat, ensuring long-term stability and durability under high-frequency charging and discharging conditions.
Customizable to meet specific requirements for vehicle model, connector type, wire gauge, and length, ensuring perfect compatibility with a wide range of vehicles.
Product Certifications: Compliant with CE, FCC, RoHS, and UL certifications
